Overview
This is a high-pressure ball valve for grease, with a maximum operating pressure of 20.6 MPa. By installing it on the pump discharge line, it makes pump maintenance easier.
Specifications
| Model | Material | Operating pressure | Screw diameter | Mass |
|---|---|---|---|---|
| HT0210-8 | S30C-L | MAX.20.6㎫ | Rc1/4 | 0.6㎏ |
| HT0210-10 | Rc3/8 | 0.8㎏ | ||
| HT0210-15 | Rc1/2 | 1.2㎏ | ||
| HT0210-20 | Rc3/4 | 1.8㎏ |
Model description
HT0120–8
Series name
Screw diameter
- 8：
- Rc1/4
- 10：
- Rc3/8
- 15：
- Rc1/2
- 20：
- Rc3/4
PDF files of catalogues are available.
